Ultra-wide FoV Metalens Monochromatic IR Camera
Ultra-wide FoV Single Layer Metalens Monochromatic IR Camera At 740nm
Compact wide monochromatic camera for applications such as eye tracking, facial recognition, AR/VR, and monochromatic imaging. 12'' Glass Wafer DUV Immersion Photolithography Manufacturing Process. Inclusive of advanced software with AI enhancement functions. Camera assembly process is tunable to fit a variety of other applications.
Specifications
Expand/Collapse All
Mechanic

mechanical Dimensions

  • thickness: 10mm
  • length: 47mm
  • width: 44mm
Camera

camera Specifications

  • focal Length: 2mm
  • field Of View: 179° ± 1.2°
  • sensor Type: Monochrome CMOS
  • peak Quantum Efficiency: 65% @ 535 nm
  • resolution: 1.6 MP
  • active Pixels: 1440 x 1080
  • pixel Size: 3.45 µm x 3.45 µm
  • imaging Area: 4.968 mm x 3.726 mm
  • adc Resolution: 10 bits
  • sensor Shutter Type: Global
  • exposure Time: 0.04 ms – 26.843 ms
  • usb Power Consumption: 1.17 W
  • ambient Operating Temperature: 10 °C – 40 °C
  • storage Temperature: 0 °C – 55 °C
Metalens

metalens Specifications

  • minimum Pillar Diameter: 80nm
  • pitch Between Pillars: 300nm
  • height Of Pillars: 350nm
  • lens Diameter: 5mm
